| Price: | CN¥128,612.12-136,198.79/sets |
Product Application of essential oil extraction equipment.
KINETIC brand,Our essential oil extraction equipment is popular in production of health products,biological drugs,cosmetics and food .This uses technology and chemical separation,can extract plant components efficiently by steam distillation , have good effect in collecting essential oil from plants.
1, Extracting tank 2, Oil-water separator 3, Receiver 4, Oil cooling system 5, Plate distillation system
6, Vacuum system 7, Frame 8, Pipes 9, Valves 10, Digital temperature sensor.
( PS:Installation&adjusting,We will assemble and test the machine before packing. Also send English manual brochure,we will provide one engineer to assemble and train workers. )
(1)By steam-distillation to reach the extraction of essential oils.
(2)Easy operation. One people can operate this machine easily .
(3)High efficiency. Using indirect heating of heat- transfer oil, it can quickly reach 100℃ high temperature under the conditions of cleanness, safety and atmospheric pressure. If required, with vacuum pump, the extraction speed of essential oils will be ore faster.
(4)Maded with 304 Stainless steel with the density absolutely free from the erosion of essential oil.
(5) Environmentally friendly . no smoke, no odor, without secondary pollution, the whole process is all sealed, won't release any gas harmful to human and environment.
Distillation kettle | Effective volume: 800L, using high-pressure steam through heating. Inside: working pressure: normal pressure;design temperature:120℃,work temperature≤100℃.Working medium:water; Upper oval headδ=5mm/S30408,Cylinder δ=5mm/S30408. Discharge slag door:DN1200, Three cylinder rotary slag gate, Single cylinder to open the door, two cylinder locking, a slag door with self-locking cylinder. |
Demister | Size Φ300×750,δ=3mm/S30408,Demister inside has baffle, The top of the demister is set to the quick opening hole. Demister to facilitate cleaning.Meet the GMP requirements. |
Condenser | Vertical condenser. Heat transfer area is greater than10m2 . Pipeline:designed pressure: normal pressure;working pressure: normal pressure;design temperature:100℃, work temperature≤90℃. Working medium:Secondary steam. Length:Φ25×2,Material: S30408. Shell:designed pressure: 0.3Mpa,working pressure: normal pressure;design temperature:50℃,work temperature:15~30℃. Working medium:cooling water. Size and material:δ=3mm/S30408 |
Pure dew collection tank | material 304 stainless steel,volume 1m³ |
Oil water separator | Stainless steel tank,Glass as the cup,Dedicated oil - water separator. Volume: 40L,size δ=3mm/S30408 |
double filter | 120 mesh filter,flow 6.0m3/h,material S30408. |
Description | Raw material | Description | Raw material |
Gaultheria procumbens essential oil distiller | Gaultheria procumbens leaf | Cinnamomum cassia essential oil distiller | Cinnamomum cassia Cinnamon bark |
Achillea millefolium essential oil distiller | Achillea millefolium Flowers and upper branches | Santalum album essential oil distiller | Santalum album Wood core and root core |
Cymbopogon nardus essential oil distiller | Cymbopogon nardus Leaf blade | Matricaria chamomilla essential oil distiller | Matricaria chamomilla flowers |
Pimenta dioica essential oil distille | Pimenta dioica seeds | Anthemis nobilis essential oil distiller | Anthemis nobilis flowers |
Angelica archengelica essential oil distiller | Angelica archengelica root | Cinnamomum zeylanicum essential oil distiller | Cinnamomum zeylanicum Wood core and root core |
Angelica archengelica essential oil distiller | Angelica archengelica seeds | Salvia sclarea essential oil distiller | Salvia sclarea Leaf and upper branch |
Pimpinella anisum essential oil distiller | Pimpinella anisum seeds | Eugenia caryophylatta essential oil distiller | Eugenia caryophylatta bud |
Arnica montana essential oil distiller | Arnica montana root | Eugenia caryophylatta essential oil distiller | Eugenia caryophylatta Leaf |
Related production:
10L 100L 500L 3000L
Packing | ||
Size | To be determined | |
Weight | bdepend on model | |
Packaging Details | The normal package is wooden box. If export to European countries, the wooden box will be fumigated.If container is too weight, we will use per film for packing or pack it according to customers special request. | |
Delivery | ||
tool | Ship, express or Air | |
Packing | In containers | |
Shipping Details | The normal shipping method is by sea. We also accept Air Transporting if you are in urgent need. You can contact your own shipping agent or ask us to arrange shipping for you. | |
Our service:
Pre-sales service
1.Quick response
2.Detailed quotation
3.Professional production and transportation solution
After-sales service
1.One year warranty
2.we will provide one engineer to assemble and train workers.
3.7*24 hours technical support by mail/whatsapp/skype/wechat/ mobile phone.
Q1: What is the Warranty for the machines?
A1: 1 year for free.
Q2: What is the Material?
A2: Stainless steel.
Q3: When can I get the price?
A3: Within 24 hours, if urgent, please directly call us.
Q4: Whether the machine price can be more discount?
A4: In general, our MOQ is 1set with very reasonable price, but if large order, we also can apply to our Manager to appropriately give you a little discount.
Q5: How to ask quotation?
A5: Please note us what type of raw materials , and how many kinds of raw materials you want to treat per batch, then we will send you quotation as soon as we can.
Q6: Can we ask the oil plant for different types of oil?
A6: Yes, but we recommend no more than 3 different types.
Q7: Essential oil plants require how large of a workspace?
A7: The land area typically depends on the capacity of the plant. We can suggest an appropriate space to prepare after given specifications, or, can design the oil plant in-house specifically to the amount of workspace available.
Q8: How long will it take to receive my products?
A8: As a general rule, it will take one Month for us to produce.
Q9: Do you offer oversea installation?
A9: We'll send professional installation engineer to help you install the equipment, as well as training your workers freely.
|
|
