| Brand Name: | Fumoter |
| Model Number: | Fumoter-KC-120KW |
| MOQ: | 2 sets |
| Price: | CN¥62,370.68/sets >=2 sets |
Rated power | 120KW |
User interface | 7-inch LCD color display touch screen |
Installation method | floor standing |
Cable length | 5m |
Working temperature | -25 ℃~+50 ℃ |
Working humidity | 5%~95% (Non Coagulation Frost) |
Working altitude | <3000M |
Protection level | IP54 |
Cooling method | Forced air cooling |
noise control | ≤ 60dB |
MTBF | 100,000 hours |
Input frequency | 45-65Hz |
Output voltage | 200-750V constant power |
Single gun output current | 0-250A |
Measurement accuracy | 0.5 level |
Current limiting protection value | ≥ 110% |
Stable voltage accuracy | ≤ ± 0.5% |
Stable current accuracy | ≤ ± 1% |
Ripple coefficient | ≤ ± 0.5% |
Efficiency | ≥ 94.5% |
power factor | ≥0.99（More than 50% load） |
Harmonic content THD | ≤ 5%（More than 50% load） |
Human machine interface | 7-inch LCD color display touch screen, LED indicator lights |
Charging mode | Automatic filling/Fixed electricity quantity/Fixed amount/Set time |
Communication interface | Ethernet 2/3/4G (optional) |
Payment method | Card payment/QR code payment |
Executive standards | GBT |
Safety functions | Charging gun temperature detection，Overvoltage protection，Undervoltage protection，overload protection，Short circuit protection，Grounding protection，Over temperature protection，Low temperature protection，Insulation monitoring and protection，Polarity reverse protection，Lightning protection，Emergency stop protection，Leakage protection，Surge protection、Ground fault |
|
|
