| Brand Name: | MAXPOWER |
| Model Number: | 7KW |
| Price: | CN¥4,647.26/sets 1-9 sets |
|
Model
|
EVSE828-EU
|
EVSE828S-EU
|
||
|
Input&Output
|
|
|
||
|
Input voltage(AC)
|
AC220V(L+N+PE)
|
AC220V(L+N+PE)
|
||
|
Input frequency
|
50Hz
|
50Hz
|
||
|
Output voltage
|
220V AC
|
220V AC
|
||
|
Max.output power
|
7KW
|
7KW
|
||
|
Max.output current
|
32A
|
32A
|
||
|
Charger interface type
|
IEC62196-2, type 2
|
IEC62196-2, type 2
|
||
|
Protection
|
|
|
||
|
Overvoltage protection
|
Yes
|
Yes
|
||
|
Undervoltage protection
|
Yes
|
Yes
|
||
|
Overload protection
|
Yes
|
Yes
|
||
|
Shortcircuit protection
|
Yes
|
Yes
|
||
|
Earthleakage protection
|
Yes
|
Yes
|
||
|
Over-temperation protection
|
Yes
|
Yes
|
||
|
Lightning protection
|
Yes
|
Yes
|
||
|
Function and accessory
|
|
|
||
|
Ethernet/WIFI/4G
|
Yes/Yes/Opt
|
Yes/Yes/Opt
|
||
|
Connection
|
IEC62196-2
|
IEC62196-2
|
||
|
RCD
|
Type B faultcurrent protection
|
Type B faultcurrent protection
|
||
|
LED Indicator light
|
Yes
|
Yes
|
||
|
Emergency stop button
|
Opt
|
Opt
|
||
|
Charging Mode
|
RFID swipe card(Opt)
|
RFID swipe card(Opt)
|
||
|
Communication interface
|
RS-232/485 Opt
|
RS-232/485 Opt
|
||
|
Background agreement
|
Support OCPP 1.6 protocol
|
Support OCPP 1.6 protocol
|
||
|
Mean Time to Failure
|
MTBF=8796h
|
MTBF=8796h
|
||
|
Display Screen
|
7 Inches
|
7 Inches
|
||
|
With charging socket/cable
|
Opt
|
Opt
|
||
|
Working evironment
|
|
|
||
|
Protection degree
|
IP65
|
IP65
|
||
|
Evironment temperature
|
-20℃+55℃
|
-20℃+55℃
|
||
|
Relative humidity
|
5%-95% non-condensing
|
5%-95% non-condensing
|
||
|
Storage temperature
|
-40℃+70℃
|
-40℃+70℃
|
||
|
Maximum altitude
|
<2000m
|
<2000m
|
||
|
Cooling
|
Natural air cooling
|
Natural air cooling
|
||
|
Standby power consumption
|
<3W
|
<3W
|
||
|
Mechnical
|
|
|
||
|
Dimension(W/H/D)
|
400/280/120mm
|
400/280/120mm
|
||
|
Weight
|
<8KG
|
<8KG
|
||
|
Mounting
|
|
|
||
|
Mounting mode
|
Wall hanging
|
Upright
|
||
|
Moutiong accessories
|
Wall-mounting bracket
|
Ground-mounting pole
|
||
|
|
