EN61851-1-2012 IEC62196-2-2011 Standard 3-Phase 32A 22kW EV Charging Station for Home Charging Convenience and Efficiency

Name: EN61851-1-2012 IEC62196-2-2011 Standard 3-Phase 32A 22kW EV Charging Station for Home Charging Convenience and Efficiency
Brand: Hubei Xinyanmei Supply Chain Management Co., Ltd.
SKU: AC22032E
Price: Negotiable USD
Availability: InStock

Brand Name:	Max power
Model Number:	AC22032E
Price:	CN¥3,897.23/sets 1-4 sets

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Output Power:

Product Name:

Ac Ev Charging Pile

Rated Power:

22kW

Output Current:

32A

IP Level:

IP65

Parking Size:

535*315*190mm

Input / Output Voltage:

400V(Three Phase)

Weight:

12kg

Input Frequency:

50/60Hz

LCD:

4.3-inch Color Display

Standard:

EN61851-1-2012 IEC62196-2-2011

Product Description

Product Overview

*This product is a 11KW three-phase AC charging pile, mainly used for AC charging of electric vehicles. The product is composed of charging pile body, wall-hanging backboard, floor-to-ground column (optional), etc., with charging protection, charging by swiping card, charging by scanning code, mobile payment,networking monitoring and other functions.This product adopts industrial design principle, easy to install and easy to use.
*Exterior:Exquisite and light, a variety of color options, suitable for different application scenarios.
*Protection:level of protection IP65(waterproof and dustproof),can withstand wind,rain and sun exposure.
*Operation:The head of the charger is designed to open the cover with one bottom. The operation is simple and convenient, namely plug and play.
*Safety:multiple protection, safety upgrade, high quality materials, fireproof, waterproof and dustproof.
*Commonality:Small body, big energy, compatible with 99% of the new energy vehicles.
*Quality:Pure copper wire without oxidation,comply with inspection standard,flame retardant impact resistance.
*The performance of the charger meets the requirements《IEC 62196-2-2011 Plugs,socket-outlets,vehicle connectors and vehicle inlets-Conductive charging of electric vehicles Part 2》relevant regulation.
*According to 《IEC 61851-1-2012 Electric Vehicle Conductive Charging System Part 1》relevant regulation, and with reference to the "Electric Vehicle Charging Facilities Typical Design" part of the function of the design.The products fully meets the national and industrial standards for electric vehicles.

ELECTRICAL SPECIFICATION
Input Voltage/Output voltage	400V(Three Phase)
Input frequency	50/60Hz
Max. output power	22kW(Three Phase)
Max. output current	32A
WORKING ENVIRONMENT
Protection degree	IP65
Environment temperature	-25℃ ~ +55℃
Relative humidity	0-95% non-condensing
Maximum altitude	<2000m
Cooling	Natural air cooling
MOUNTING ACCESSORIES
Wall-mounting bracket/Ground-mounting pole	Yes/Opt
PRODUCT MODEL(11kW)	GD4502-052	GD4502-053	GD4502-054	GD4502-055
Vision	Family	Operation	Family(socket)	Operation(socket)
APP/Ethernet/WIFI	Yes	Yes	Yes	Yes
4G	Opt	Yes	Opt	Yes
RFID	Yes(with NFC)
LCD	4.3-inch color display
RCD	Type A / Type B
LED Indicator light	Yes
Intelligent power adjustment	Yes

Recommanded For You

Please feel free and click here for more information.

Company Profie

Please feel free and click here for more information.

Exhibition

Packaging and shipping

Customer Reviews

Please feel free and click here for more information.

FAQ

Q1.Are you a factory or trading company?
A: We are a professional manufacturer of new and sustainable energy applications for over 18 years.
Q2.What is the warranty?
A: 12 months. In this period, we will supply technical support and replace the new parts by free,customers are in charge of
delivery.
Q3. What is your terms of packing?
A: Generally, we pack our goods in brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q4. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q5. What is your terms of trade?
A: EXW, FOB, CFR, CIF, DAP,DDU,DDP
Q6. How about your delivery time?
A: Generally, it will take 3 to 7 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q7. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q8. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q9. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q10.What’s the difference between Movable Charger and Wallbox Charger?
A: In addition to the obvious appearance difference, the main protection level is different: wallbox charger protection level is IP54, available outdoors;And the Movable Charger protection level is IP43, rainy days and other weather can not be used outdoors.
